⚙️ Transmissions it Fits:
-
A904 (also called 30RH)
-
A500 (also called 40RH / 42RH / 42RE / 44RE)
-
A727, A518, A618, 46RH, 46RE, 47RH, 47RE, 48RE — when configured with 4WD tail housings
These are all Chrysler/RWD automatic transmissions, and the 4WD version has a larger tail housing bore that requires this specific seal size.
🚙 Common Vehicle Applications:
| Make | Model | Notes |
|---|---|---|
| Dodge | Ram 150 / 1500 (early models) | With A500/A518 4x4 trans |
| Dodge | Dakota (4WD) | With 42RE/44RE |
| Jeep | Grand Cherokee / Cherokee | With 42RE 4WD |
| Dodge | Ramcharger, Ram Van (4WD) | Various A500-series trans |
| Jeep | Wagoneer / Comanche (4x4) | Some early A904 4x4 setups |
📏 Technical Specs:
| Spec | Value |
|---|---|
| Outer Diameter (OD) | 2.568 inches |
| Inner Diameter (ID) | Approx. 1.68 inches |
| Width/Height | ~0.5 inches (varies slightly) |
| Construction | Metal-clad rubber seal |
| Features | Spring-loaded lip, dust boot (on some variants) |
| Seal Type | Rear output/yoke seal for 4WD housing |
🔁 Cross-Reference & Alternate Part Numbers:
| Brand | Part Number |
|---|---|
| National | 36074 |
| Timken | 36074 |
| SKF (CR) | 18731 |
| Chrysler OEM | 52108336 (or similar OE tailshaft seals) |
⚠️ Important Distinction:
There are two types of A904/A500 extension housing seals:
| Part Number | OD | Application |
|---|---|---|
| 12074J | 2.568" | 4WD (4x4 only) |
| 12074 or 12074M | ~2.506" | 2WD or compact applications |
Do NOT interchange these — the difference in OD makes them incompatible.
🛠️ Usage Notes:
-
If you're working on a 4x4 vehicle , especially with a transfer case attached directly to the transmission, this is the correct seal .
-
Install using a seal installer or large socket , tap in evenly.
-
Grease the inner lip before sliding in the output shaft to prevent dry wear.
⚙️ Transmissions it Fits:
-
A904 (also called 30RH)
-
A500 (also called 40RH / 42RH / 42RE / 44RE)
-
A727, A518, A618, 46RH, 46RE, 47RH, 47RE, 48RE — when configured with 4WD tail housings
These are all Chrysler/RWD automatic transmissions, and the 4WD version has a larger tail housing bore that requires this specific seal size.
🚙 Common Vehicle Applications:
| Make | Model | Notes |
|---|---|---|
| Dodge | Ram 150 / 1500 (early models) | With A500/A518 4x4 trans |
| Dodge | Dakota (4WD) | With 42RE/44RE |
| Jeep | Grand Cherokee / Cherokee | With 42RE 4WD |
| Dodge | Ramcharger, Ram Van (4WD) | Various A500-series trans |
| Jeep | Wagoneer / Comanche (4x4) | Some early A904 4x4 setups |
📏 Technical Specs:
| Spec | Value |
|---|---|
| Outer Diameter (OD) | 2.568 inches |
| Inner Diameter (ID) | Approx. 1.68 inches |
| Width/Height | ~0.5 inches (varies slightly) |
| Construction | Metal-clad rubber seal |
| Features | Spring-loaded lip, dust boot (on some variants) |
| Seal Type | Rear output/yoke seal for 4WD housing |
🔁 Cross-Reference & Alternate Part Numbers:
| Brand | Part Number |
|---|---|
| National | 36074 |
| Timken | 36074 |
| SKF (CR) | 18731 |
| Chrysler OEM | 52108336 (or similar OE tailshaft seals) |
⚠️ Important Distinction:
There are two types of A904/A500 extension housing seals:
| Part Number | OD | Application |
|---|---|---|
| 12074J | 2.568" | 4WD (4x4 only) |
| 12074 or 12074M | ~2.506" | 2WD or compact applications |
Do NOT interchange these — the difference in OD makes them incompatible.
🛠️ Usage Notes:
-
If you're working on a 4x4 vehicle , especially with a transfer case attached directly to the transmission, this is the correct seal .
-
Install using a seal installer or large socket , tap in evenly.
-
Grease the inner lip before sliding in the output shaft to prevent dry wear.
- Regular price
- $9.99
