AUTOTTEC A4LD EARLY MODEL SERVICE KIT
Years:
1985 - 1988 |
Transmission:
Ford A4LD (Hydraulic / Vacuum Controlled) |
Drive:
2WD
Applications:
Ford Ranger (2.3 L / 2.9 L) • Bronco II (2.8 L / 2.9 L) • Aerostar (2.3 L / 2.8 L / 2.9 L) • Mustang 2.3 L • Merkur Scorpio 2.9 L V6
Kit Code:
AUTOTTEC-K-A4LD-E85
🧩 KIT COMPONENTS
| OE Number | AUTOTTEC Reference(s) | Description / Details |
|---|---|---|
| E6TZ-7A098-B | 56010E / 56710A | Filter / Strainer + Extension Housing Seal - Metal-neck short filter for A4LD 2WD (1985-1988) hydraulic units. Includes rear seal (56710A) for output shaft yoke. |
| E5TZ-7A191-A | 56300E / F56500F | Pan Gasket + Support Set - 18-bolt molded-rubber reusable gasket for A4LD (85-94) and later 4R44E / 4R55E / 5R55E pans. Includes modulator support hardware (F56500F). |
| E5TZ-7A377-B | 56833 / 56160E | Vacuum Modulator Valve + Bolt Set - Adjustable screw-tip modulator for early hydraulic A4LD (1985-1988 2WD). Includes pan bolt set (56833). |
⚙️ FITMENT SUMMARY
| Vehicle | Engine(s) | Drive | Years |
|---|---|---|---|
| Ford Ranger | 2.3 L / 2.9 L | 2WD | 1985 - 1988 |
| Ford Bronco II | 2.8 L / 2.9 L | 2WD | 1985 - 1988 |
| Ford Aerostar | 2.3 L / 2.8 L / 2.9 L | 2WD | 1986 - 1988 |
| Ford Mustang | 2.3 L (4-cyl) | 2WD | 1986 - 1988 |
| Merkur Scorpio | 2.9 L V6 | 2WD | 1987 - 1989 (Early Style) |
📦 KIT CONTENTS
✅ Filter + Rear Seal -
56010E / 56710A
(OE E6TZ-7A098-B)
✅ Pan Gasket + Support Set -
56300E / F56500F
(OE E5TZ-7A191-A)
✅ Vacuum Modulator + Bolt Set -
56833 / 56160E
(OE E5TZ-7A377-B)
⚙️ TECH NOTES
-
For A4LD Hydraulic (Vacuum-Modulated) transmissions only.
-
Fits 2WD models with short metal-neck filter.
-
4WD models use long-neck filter variant (not included).
-
Later 4R44E / 4R55E / 5R55E units are electronic (no modulator).
-
Recommended Fluid: MERCON / DEXRON III ATF .
-
Always verify 18-bolt pan pattern and filter neck length before installation.
